Radial/Deep Groove Ball Bearing - Straight Bore, 25 mm ID, 62 mm OD, 17 mm Width, Double Sealed, Without Snap Ring

Specifications

• Height
  0.866
• Bore Type
  Straight
• Length
  2.52
• Bore Diameter


• Width
  2.677
• Outside Diameter


• Overall Width


• Closure Type
  Double Sealed
• Row Type Fill Slot
  Single Row Non-Fill Slot
• Snap Ring Included
  Without Snap Ring
• Precision Rating
  ABEC 1 (ISO Class Normal)
• Finish Coating
  Uncoated
• Cage Material
  Steel
• Fillet Radius
  1 mm
• Max Rpm
  14000 rpm
• Series
  300-S
• Radial Dynamic Load Capacity
  4760 lbf
• Radial Static Load Capacity
  2430 lbf
• Manufacturer Catalog Number
  305SZZ
• Additional Details
  Open bearing: Prefix designation S , Sealed on both sides: Prefix designation ZZ , Shielded on both sides: Prefix designation FF , Snap ring groove: Prefix designation G
• Features & Benefits
  • Single-row radial deep groove bearing can carry significant radial loads, and, because of the uninterrupted raceway grooves and the high degree of conformity between balls and raceways, it can carry substantial thrust loads in either direction, even at very high speeds
• Description
  305 SZZ BRG
• Product Type
  Radial & Deep Groove Ball Bearings
